Scratch and dent new

Front Control Design

• Effortlessly upgrade your back-control range to built-in style. This range will easily replace traditional 30" freestanding ranges.

Perfect Taste™ Convection

• For consistently delicious taste and texture, home chefs rely on our convection heat, which circulates air evenly for better baking.

Oval Burner + Included Griddle

• Allows you to cook with larger pots and pans or use the complementary griddle to achieve a variety of perfect flavors.

Perfect Taste™ Temp Probe

• Alerts you when your roast has reached perfection, then automatically adjusts heat to a Keep Warm setting.

Min-2-Max® Gas Burner

• Designed with a dual-flame sealed burner, this cooktop provides exceptional power and precision to unlock new flavors

Warmer Drawer

• Maintain the perfect temperature of your food until serving time.

A Luxury-Glide ® Oven Rack

• With a ball bearing system, the oven rack is so smooth it extends effortlessly so you can easily manage the transfer of all dishes.

Continuous Gas Grates

• Designed for cooking multiple dishes at a time, these grates allow easy movement of pots and pans from burner to burner - without lifting.

Deep-Well Design

• Keeps spills contained for easy cleanup.

Convection Conversion

• Automatically adjusts standard baking temperatures to convection temperatures, for perfect, consistent results.

Keep Warm Setting

• Maintain food at the perfect serving temperature with this setting — it’s a great feature when you’re entertaining.

IQ Touch™ Controls

• The IQ TouchTM control panel displays all of your options, at all times.

Signature Cobalt Blue Interior

• Provides a sleek, premium look even when your oven is open.

Multiple Self-Clean Options with Automatic Door Lock

• Provides easy self-cleaning while keeping your family safe during the process.

7 Cooking Modes

• Bake, Broil, Convection Bake, Convection Roast, Convection Broil, Keep Warm and Slow Cook

Platinum Star® Limited Warranty

• Our exclusive warranty offers peace of mind for registered owners with two years of coverage on replacement parts.

Certifications and Approvals
ADA Compliant	Yes
Star-K Certification	Yes

Controls
Control Lock	Yes
Sabbath Mode	Yes

Cooking Controls
Add A Min	Yes
Bake	Yes
Broil	Yes
Cancel	Yes
Clock	Yes
Convection Bake	Yes
Convection Convert	Yes
Convection Roast	Yes
Cooktop Lockout	No
Dehydrate	No
Delay Clean	Yes
Delay Start	Yes
Keep Warm	Yes
Kitchen Timer	Yes
Lockout	Yes
Off	Yes
Oven Light	Yes
Perfect Turkey	No
Preheat	Yes
Probe	Yes
Quick Preheat	No
Rapid Preheat	No
Self Clean	Yes
Slow Cook	Yes
Temperature Display	Yes
Timed Bake	Yes
Warmer Drawer	Yes

Cooktop
Cooking Surface Type	Gas
Grate Material	Cast Iron
Grate Style	Edge to Edge

Cooktop Performance
Right Front Element Burner	18,000 BTU
Right Rear Element Burner	5,000 BTU
Left Front Element Burner	9,500 BTU
Left Rear Element Burner	14,200 BTU
Center Element Burner	10,000 BTU

Dimensions and Volume
Height	36 5/8"
Width	29 7/8"
Depth	28 5/16"
Depth With Door 90° Open	46"
Oven Interior Height	17 1/2"
Oven Interior Width	24 1/8"
Oven Interior Depth	18 3/4"
Oven Capacity	4.5 Cu. Ft.

Display
Display Interface Color	Blue
Display Type	Capacitive Touch

Drawer
Drawer Type	Warmer

Electrical Specifications
Minimum Circuit Required	15 Amps
Voltage Rating	120 V

Exterior
Cooktop Finish	Stainless Steel
Drawer Finish	Stainless Steel
Handle Color	Stainless Steel
Handle Material	Stainless Steel
Knob Color	Stainless Steel

General Specifications
Product Weight	256.5 lbs
Prop 65 Label	Yes
Warranty - Labor	1 Year
Warranty - Parts	1 Year

Installation
Adjustable Leveling Legs	Yes
Gas Supply Connection Location	Bottom Right
LP Conversion Kit Included	Yes
Power Cord Included	Yes
Power Supply Connection Location	Bottom Right

Oven
Bake Element	18,000 BTU
Bake Element	450 Watts
Bake Element Type	Hidden
Bake System	Yes
Broil System	Yes
Convection Element	350 Watts
Convection Type	Total
Number of Rack Positions	5
Oven Interior Color	Cobalt Blue
Rack Position Type	Nickel Ladder
Rack Type 1	Handle
Rack Type 1 Quantity	1
Rack Type 2 Quantity	1
Rack Type 3	Glide
Rack Type 3 Quantity	1
Window Type	Extra Large Window

Safety Certifications and Approvals
CSA Listed	Yes
ETL Listed	No
